Mitsubishi MS-T65 Enclosed DOL Motor Starter 3P 43–65A 54A 30kW 380V AC | MST65 KPPMCG-54A

Description

Mitsubishi MS-T65 Enclosed DOL Motor Starter 3P 43–65A 54A 30kW 380V AC | MST65 KPPMCG-54A

- Product Type: Enclosed Direct-On-Line (DOL) Magnetic Motor Starter
- Series: MS-T
- Starter Frame: MS-T65
- Compatible With: Three-Phase AC Motors Drawing 43–65 A
- Adjustable Overload Range: 43–65 A
- Heater Designation: 54 A
- Contactor Rated Current: 65 A at 380–440 V AC, AC-3
- Conventional Free-Air Thermal Current: 100 A
- Number of Poles: 3P
- Main Contact Arrangement: 3NO
- Auxiliary Contacts: 2NO+2NC
- Motor Circuit: Three-Phase AC
- Control Supply Voltage: 380 V AC
- Rated Operational Voltage: Up to 690 V AC
- Rated Insulation Voltage: 690 V
- Rated Motor Power: 30 kW at 380–440 V AC
- Integrated Components: Magnetic Contactor and Thermal Overload Relay
- Relay Technology: 2-Element Thermal Overload Relay
- Protection Functions: Motor Overload and Locked-Rotor Protection
- Coil Surge Suppression: Built-In Surge Absorber
- Enclosure Type: Enclosed Motor Starter
- Connection Type: Screw Terminals
- Main Terminal Screw Size: M6
- Control Terminal Screw Size: M4
- Mounting Type: Surface / Panel Mount
- Model: MST65 KPPMCG-54A
- Made in: Japan
- Brand: Mitsubishi Electric
- Ref: MITSB-Cont-MST65 KPPMCG-54A
- Unit: Pcs

Product form

SKU: 3037

Product Information

  • Mitsubishi MS-T65 enclosed direct-on-line magnetic motor starter configured for three-phase AC motors drawing 43–65A. It combines a 65A magnetic contactor with a 54A-designated adjustable thermal overload relay, 3NO main contacts and 2NO+2NC auxiliary contacts. This 380V AC control-supply version supports motors rated up to 30kW at 380–440V AC and features built-in coil surge suppression.
  • Brand: Mitsubishi
  • Model: MST65 KPPMCG-54A
  • Made in: Japan
  • Ref: MITSB-Cont-MST65 KPPMCG-54A
  • Unit: Pcs
