Deye Three Phase Hybrid Solar Inverter 16kW 40-60V 2 MPPT | SUN-16K-SG05LP3-EU-SM2

Description

Deye Three Phase Hybrid Solar Inverter 16kW 40-60V 2 MPPT | SUN-16K-SG05LP3-EU-SM2

-General
-Series Version: SG05LP3-EU-SM2 Series
-Rated Output Power: 16000W
-Max AC Apparent Power: 17600VA
-Battery Voltage Range: 40-60V DC
-Nominal AC Voltage: 230/400V AC
-Frequency: 50/60Hz
-Phase: Three Phase
-Mounting Type: Wall-Mounted

-Solar
-Solar Charger Type: 2 MPPT
-Maximum PV access power: 32000W

-Maximum PV Input Power: 25600W
-Maximum PV Input Voltage: 800V DC
-MPPT Voltage Range: 160-650V DC
-Maximum PV Input Current: 36A + 36A
-MPPT Trackers: 2

-Battery
-Battery Type: Li-Ion / Lead-Acid
-Charging Strategy for Li-ion Battery: Self-adaption to BMS

-Maximum Charging / Discharging Current: 300A
-Battery Inputs: 2

-Main Features
-Parallel Capability: Up to 10 Units
-Max Continuous AC Passthrough: 70A
-IP Rating: IP65
-BMS Communication: CAN / RS485
-Wi-Fi Monitoring: Supported


-Application: Villas, large homes, offices, shops, farms, and light-commercial three-phase solar energy systems.
-Size: 45.6x75x26.85cm
-Color: White
-Usage: Manages solar, battery, grid, generator, and backup power in a three-phase hybrid energy system.

-Brand: Deye
-Made in: China
-Model: SUN-16K-SG05LP3-EU-SM2
-Ref: Deye-SUN-16K-SG05LP3-EU-SM2
-Unit: Pcs

Product form

SKU: 17195

Product Information

  • 16000W, 17600VA Max, 40-60V DC, 220/380V–230/400V AC, Three Phase, 2 MPPT, 25600W Max PV, 300A Charging, IP65, Wall-Mounted, 45.6x75x26.85cm, White
  • Brand: Deye
  • Model: SUN-16K-SG05LP3-EU-SM2
  • Made in: China
  • Ref: Deye-SUN-16K-SG05LP3-EU-SM2
  • Unit: Pcs
