SEG Color Video DoorPhone 7inch (Touchpad, 4 Wire System) | SE-09KG
- 🏠Indoor Unit Specifications:
-Screen Size: 7” TFT
-Resolution: 1024 (RGB) × 600
-Dimensions: 255 × 155 × 18 mm (Model RL-L09A) / 255 × 155 × 26 mm (Model RL-L09P)
-Power Supply: AC 100–240V, 50/60Hz
-Power Consumption: .5W (standby), <12W (working)
-Operating Temperature: -10°C ~ +40°C
-Operating Humidity: 10% ~ 90% RH
-Audio Volume: <80 dB (at 30cm), adjustable (1–10 levels)
🚪 Outdoor Unit Specifications:
Camera Resolution: 700 TVL
View Angle: 70° (Horizontal)
Lens: 2.8mm
Infrared LEDs: 4 × 940nm (for night vision)
Effective View Distance: ~1.5m
Working Temperature: -15°C ~ +50°C
Talking Volume: <80dB (at 30cm)
Ring-Back Tone: <70dB (at 30cm)
Card Capacity: 20 ID cards
Dimensions: 65 × 143 × 41 mm
- Features:
Touch button design—slim, elegant, and easy to use
-4-wire connection system for stable video, audio, and power transmission
- Hands-free or handset communication options
-Waterproof, oxidation-proof, and anti-vandal outdoor panel
-Electric lock release function for remote door control
-16 selectable ringtones with adjustable volume
-Adjustable screen brightness, contrast, and color
- Night vision camera for clear video even in low light
-ID card reader supports up to 20 cards
-Modern and durable design suitable for homes, offices, or buildings
